Pipe Bend Testing Machine

Name: Pipe Bend Testing Machine
Brand: UTECH ROLLS EQUIPMENTS PVT. LTD.
Price: 1200000 INR
Availability: InStock

1200000 INR/Unit

Get a Price/Quote

Product Details:

Features Sturdy construction, Digital/Manual control, Overload protection
Operating Voltage 220V AC
Temperature 10C to 40C (operating)
Equipment Type Pipe Bend Testing Machine
Specimen Size Up to 4 inch diameter pipe
Test Range Up to 50 kN
Response Time <1 sec
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Pipe Bend Testing Machine Price And Quantity

Minimum Order Quantity 1 Unit
Price 1200000 INR/Unit

Pipe Bend Testing Machine Product Specifications

Test Width 200 mm
Specimen Size Up to 4 inch diameter pipe
Machine Weight Approx. 450 kg
Operating Voltage 220V AC
Control Mode Digital/Manual
Temperature 10C to 40C (operating)
Equipment Type Pipe Bend Testing Machine
Capacity 50 kN
Usage Pipe mechanical testing
Features Sturdy construction, Digital/Manual control, Overload protection
Application Pipe bend/bending strength test
Power Supply 220V AC, 50Hz
Mounting Type Floor standing
Resolution 0.01 kN
Number of Specimens 1 per test
Frequency 50 Hz
Max Height 1200 mm
Accuracy 1%
Port Size 1/2 inch to 4 inch
Display Type Digital display
Test Range Up to 50 kN
Response Time <1 sec

Pipe Bend Testing Machine Trade Information

Supply Ability 1 Unit Per Day
Delivery Time 3 Months
Main Export Market(s) Australia, North America, South America, Eastern Europe, Middle East, Africa, Central America, Western Europe, Asia
Main Domestic Market All India

Product Description

Pipe Bend Testing Machine is among the products we offer, and it is known for its high performance and low maintenance costs. This model combines all of the necessary components to construct the fundamentals of proper threading. This machine marks the start of a new era in measurement technology. Pipe Bend Testing Machine may be customized to meet the needs of the client at a reasonable price. In order to improve the performance and functionality of our model, we also considered the informed opinions of machine operators.

Adjustable Precision for Varied Applications

Adapt to diverse testing needs with an adjustable bend angle up to 180. This pipe bend testing machine accommodates a wide range of pipe sizes, from 1/2 inch to 4 inches diameter, providing flexibility for research, quality control, and industrial applications. Its sturdy construction ensures consistent, repeatable test results.

Advanced Safety and Digital Controls

Benefit from innovative safety features such as an emergency stop and overload protection indicator. Choose between manual or digital control modes to match your workflow. The integrated digital data logging function and display panel empower users to analyze and store test outcomes efficiently.

Effortless Installation and Operation

The machine is designed for floor mounting, ensuring stability during operation. With a compact maximum height of 1200 mm and weight of approximately 450 kg, it fits most industrial or laboratory spaces. The clear digital readout and user-friendly interface promote hassle-free setup and operation.

FAQs of Pipe Bend Testing Machine:

Q: How does the Pipe Bend Testing Machine ensure precise test results?

A: The machine features a high-resolution digital display with a resolution of 0.01 kN and an accuracy of 1%. Adjustable clamps with sturdy support ensure secure specimen placement, while the digital data logging option allows for detailed data capture and analysis.

Q: What safety features are included in this machine?

A: To enhance user safety, the equipment comes equipped with an emergency stop switch and an overload indicator. These features help prevent accidents and protect both the operator and the machine from damage during testing.

Q: When should I use this machine for pipe testing?

A: This testing machine is ideal for quality control, research, and development in manufacturing industries, laboratories, and facilities that require precise bending strength analysis on pipe samples up to 4 inches in diameter.

Q: Where can the Pipe Bend Testing Machine be installed?

A: Designed as a floor-standing unit with a powder-coated finish, this machine is suitable for installation in laboratories, industrial workshops, and quality control departments across various sectors in India.

Q: What is the typical process for conducting a test?

A: Begin by mounting the specimen using the adjustable clamps and supports. Select the desired bend angle (up to 180) and set test parameters on the digital interface. Start the test using digital or manual controls, monitor the real-time results on the display, and retrieve electronic data logs post-test.

Q: What benefits does the digital data logging feature provide?

A: Digital data logging enables seamless recording and retrieval of test data, allowing for comprehensive analysis, traceability, and easy generation of test reports. This improves accuracy and efficiency in quality monitoring and product development.
